IN-X20MAX DASH CAM

Video/Photo
Video Recording Mode Dual Recording
Video resolution 3840*2160P@30fps+ 1920*1080P@30fps
Photo resolution VGA/1M/2M/3M/5M
Video format
Video format AVI
Image format JPEG
Audio format PCM(0X1)-PCM
Camera
Image sensor OV04B10
Lens 2G+4P (lens + infrared filter), aperture F=2.0
Viewing angle
D:126°
H:110°
V:61°
Lens rotation angle Fixed
Number of cameras 2
Display
Dimensions 4-inch IPS HD display
Resolution 800*480
Type IPS
Touch Yes
Memory
CPU RAM (built-in/external) Bulit-in DDR
External Cache 4MB
Supports external storage (microSD card) 128GB (Card Speed C10 or higher)
Microphone Microphone 4015 Omnidirectional Noise-Canceling Microphone
Speaker Loudspeaker 1015 8Ω 0.5W
Auxiliary
light source
LED Night Vision Infrared Light NO
LED Fill Light NO
Product
Appearance
Interface Type-C USB port 2.5mm headphone jack TF card slot
Button 5 keys + reset button
Indicator light
Power indicator light (steady on when powered on, flashes
once per second during recording)
Power
Supply
Battery Type Polymer Lithium Battery
Battery capacity 3.7V/200mah
Maximum power consumption of this
unit
560mA（5V）
Power Supply and Charging Equipment
Input: 12-24V Output: 5V/1.5A Type-C Cable length: 3.5m
No-load voltage: ≤5.4V Load voltage: 4.6-5.2V Anti-
High and low interference
temperatures
Operating Temperature -10℃--+60℃
Storage temperature -20℃--+70℃
USB port Supported Functions (USB, PC Camera) No
Function Key Features
Loop Recording
Supports 3-axis gravity sensing
Supports Parking Monitoring / 24-Hour Parking Monitoring
(Compatible with ACC Voltage Reduction Cable)
Supports motion detection
Supports automatic locking during collisions to protect
video footage
Touch-enabled
Supports Wi-Fi
Supports one-touch lock/one-touch recording toggle
Language Available languages
English/French/Spanish/Germany/Italian/Russia/Japanese/C
hinese/Traditional Chinese
External
Dimensions
Dimensions 112.4*64.2*30.6mm
Weight
Weight without accessories (including
battery)
145g
Standard
Accessories
Standard Accessories
Car charger
Suction Cup/3M Mount (Optional)
Instruction Manual
Rear camera
Parking Info.
Package Dimensions 18*6.3*16.5 CM
Quantity 40pcs/CTN
Net Weight 24.84 kg
Gross weight 25.8 kg
Outer box dimensions 66*37.5*35 CM
